RC52832B

Chip:nRF52832

Frequency:BLE5.0

TX Power:+4dBm

Antenna:PCB

Distance:500m

Dimension:24.8*15mm

Feature:High performance

Product introduction:RC52832B is a Bluetooth Low Energy data module built on basis of the Nordic nRF52832 which is embedded with ARM ® Cortex ® -M0. The module comes with hardware version and you can have secondary development.

describe

Nordic nRF52832 BLE module slave, master, master & slave, beacon protocol module



RC52832B is a Bluetooth Low Energy data module built on basis of the Nordic nRF52832 which is embedded with ARM ® Cortex ®-M0.The module comes with hardware version and you can have secondary development.



AT command:

  • Aquire / Set Name

  • Aquire / Set Firmware version

  • Aquire / Set Device MAC address

  • Aquire / Set whether echo

  • Aquire / Set whether display device state

  • Aquire / Set broadcast parameters of slave role

  • Aquire / Set connection interval

  • Aquire / Set related parameters of BLE service

  • Disconnect current connected device

  • Aquire / Set related parameters of Beacon

  • Aquire / Set device role

  • Aquire / Set device power

  • Aquire / Set device sleep

  • Aquire / Set baud rate

  • Aquire / Set user authentication

  • Reset device

  • Restory



Slave mode

  • UUID: 128-bit

  • Transparent transmission

Beacon mode

  • Major 0x0102

  • Minor x0304

  • RSSI -50

  • UUIdD 0x01, 0x02, 0x03, 0x04,0x05, 0x06, 0x07, 0x08,0x09, 0x0A, 0x0B,
    0x0C,0x0D, 0x0E, 0x0F, 0x10

  • Company ID 0x0059(Nordic)

  • nrf52832 ble modulenrf52832 receiver



Recommended Footprint

图片关键词


Pin Attributes

图片关键词






PinNameChip PinPin TypeDescription
1GNDGNDGNDGND
2VCCVCCPowerPower supply 1.7 V ~ 3.6 V, Recommend 3.3 V
3P21P0_21/RESETI/OReset
4P22P0_22I/O
5P23P0_23I/O
6P24P0_24I/O
7P25P0_25I/O
8P28P0_28/AIN4I/O
9P29P0_29/AIN5I/O
10P30P0_30/AIN6I/O
11P26P0_26I/O
12P27P0_27I/O
13P02P0_2/AIN0I/O
14P03P0_3/AIN1I/O
15P04P0_4/AIN2I/O
16P05P0_5/AIN3I/O
17P06P0_6I/O
18P07P0_7I/O
19P08P0_8I/O
20P09P0_9I/O
21P10P0_10I/O
22P11P0_11I/O
23P12P0_12I/O
24P13P0_13I/O
25P14P0_14I/O
26P15P0_15I/O
27P16P0_16I/O
28SWDIOJTAG SWDI/O
29SWCLKJTAG CLKI/O
30P17P0_17I/O
31P18P0_18I/O
32P19P0_19I/O
33P20P0_20I/O
